1. Wireless Repeater Mode
Captures the host router's Wi-Fi signal and rebroadcasts it into previously unreachable zones, expanding wireless coverage across concrete walls, multiple floors, and outdoor patios without extra cabling.
B2B Wholesale Hardware Solution
Industrial-Grade 2.4GHz Wireless Coverage Expansion
The PunnkFunnk 300Mbps WiFi Range Extender provides reliable signal amplification across residential, commercial, and hospitality spaces. Engineered with high-efficiency 2.4GHz Wi-Fi chipsets, this compact wall-plug repeater eliminates signal dead spots, wall interference, and bandwidth throttling.
- 300Mbps Transmission Speed: IEEE 802.11b/g/n compliant for HD streaming and IoT connectivity.
- Dual Working Modes: Seamless switching between Repeater Mode (Wireless Extender) and AP Mode (Access Point).
- Universal Plug & Play: One-touch WPS physical pairing with standard wireless routers worldwide.
- Global Certification Compliance: Pre-certified for CE, FCC, RoHS, and WPA2-PSK encryption protocol.
Bulk Procurement Notice: Custom plug configurations (EU, US, UK, AU), private branding packaging, and localized firmware flash options available for bulk procurement.
Engineering Specifications
Technical Datasheet & Operational Parameters
Built on stable hardware Bill of Materials (BOM) to ensure long-term availability and minimal RMA rates for global retail chains.
Wireless & Radio Frequency Performance
Wireless StandardIEEE 802.11b / 802.11g / 802.11n
Operating Frequency2.4GHz - 2.4835GHz Band
PHY Data ThroughputUp to 300Mbps Dynamic
Wireless SecurityWPA-PSK / WPA2-PSK / WEP (64/128-bit)
Antenna ArchitectureIntegrated High-Gain Internal/External Antennas
Receiver Sensitivity-68dBm@10% PER (300M rate)
Hardware, Mechanical & Compliance
Physical Interface1x 10/100Mbps Ethernet LAN/WAN Port
Input Power RequirementAC 100V–240V, 50/60Hz (Universal)
Plug ConfigurationsUS / EU / UK / AU Interchangeable Pins
LED DiagnosticsPower, Wi-Fi Signal, LAN, WPS Status
Factory Testing100% Full-Load Aging & Radio Calibration
CertificationsCE, FCC, RoHS Compliant
Deployment Scenarios
Dual Operational Modes for Flexible Networking
2. Access Point (AP) Mode
Connects to a wired network router via the onboard RJ45 Ethernet port to transform existing wired internet connections into a private, high-speed 2.4GHz Wi-Fi hotspot for office rooms and hotel suites.
3. Ethernet Media Adapter Function
Acts as a wireless bridge using the integrated LAN port to connect wired-only devices—such as Smart TVs, IP cameras, desktop PCs, and gaming consoles—directly to the extended Wi-Fi network.
Factory Direct Assurance
Quality Control Standards for Global Importers
Field failures in networking hardware cost brands revenue and reputational trust. At PunnkFunnk, our manufacturing workflow ensures hardware resilience and thermal efficiency across continuous operational loads.
- Rigorous Burn-in Protocol: 100% of production units undergo continuous high-temperature power cycling before final batch boxing.
- Stable BOM Sourcing: Consistent IC chipsets and power supply modules ensure zero unexpected engineering changes between batch shipments.
- Customized OEM Branding: Complete support for silkscreen logo printing, customized SSID firmware, localized GUI, and retail box artwork.
- Batch Traceability: Individual barcode labeling links every unit to its production line lot for rapid technical support and warranty matching.
Commercial Procurement FAQ
Frequently Asked Questions for Wholesale Buyers
What is the minimum order quantity (MOQ) for custom OEM orders?
Standard factory-branded units carry low MOQs starting at 100 units. For customized OEM logo printing, localized user manuals, and custom retail packaging, OEM production lines typically begin at 1,000 units per batch.
Does this 300Mbps repeater support universal routers and regional voltage?
Yes. The hardware integrates an auto-switching 100V–240V power supply module compatible with standard global mains. The firmware complies fully with standard IEEE 802.11b/g/n protocols and pairs seamlessly with any standard wireless router or gateway.
What certificates are available for regional customs clearing?
Full CE, FCC, and RoHS test reports and certificates are available for international verification. Additional regional safety certificates can be provided upon bulk contract agreement.
Can you pre-configure firmware settings or localized SSIDs for telecom tenders?
Yes. Our in-house firmware engineering team can pre-load default SSIDs, admin credentials, customized Web GUI branding, and regional power parameters prior to factory packing.
Start Sourcing
Request Wholesale Pricing & OEM Datasheet
Connect with our OEM export team for volume discounts, shipping quotes, and customized firmware solutions.
